เครื่องทดสอบกล้องวงจรปิด HD Camera Tester IP With POE 7นิ้ว รองรับ5in1 8Mpx 4K.2651P รุ่นIPCXS-ACHT /PTZ RS485 /HDMI IN/OUT รับPOE ราคาถูก
เครื่องTESTER IP FULL SYSTEM,รองรับระบบLAN ทุกชนิดและกล้อง Analog เดินสายRG6, IP CAMERA, 4ระบบ AHD TVI CVI ,8Mpx,ตั่งค่า SET เซ็ทระบบแลน รีพอท Report ข้อมูลออกมาได้,TEST LANในตัว เทสทดสอบสัญญาณภาพ ราคาถูก,จอ7นิ้ว,รองรับ4K
HD Camera Tester IP With POE 7นิ้ว รองรับ5in1 8Mpx 4K.2651P รุ่นIPCXS-ACHT /PTZ RS485 /HDMI IN/OUT
รองรับการตั่งค่าแบบWIFI TVI 8MP(3840*2156 15P), CVI 8MP (3840*2156 15P),AHD 8MP(3840*2156 15P),
Support IP+Analog Camera, coax TVI, CVI, AHD, Camera, SDI camera.
ราคา 8,900 บาท/ชุด
รุ่น : TST0006 (รหัสสินค้า : P01858)
รายละเอียดสินค้า
Product Model : IPCX Video Monitor Tester
Touch Screen : 7 inch G+G structure capacitance screen
LCD Screen : 7 inch resolution 1920x1200 IPS HD full view
Ethernet Port : 10/100/1000M adaptive
WIFI : Built-in wireless WIFI, speed 150M
IP Camera Test : 4K H.265 IP camera test, video image real-time display without delay, support video snapshot, recording and playback
ONVIF : ONVIF tool, support DAHUA, HIKVISION, ACTI, SAMSUNG and other more than 30 manufacturer private protocols and customized, support camera mobile client installation
PTZ Control : Support Pelco-D/P, Samsung, Panasonic, etc. more than 30 protocols
CVBS Analog Camera Test : 1 channel CVBS analog signal input, support PAL/NTSC format adaptation
HD Camera Test: Support HD TVI 8MP, CVI 8MP, AHD 5MP
Video Image Zoom: Real-time enlarge moving HD video image, max enlarge 8 times
Cable Test: Built-in cable testing tool, check cable sequence and breakpoint, etc
Audio Test: One channel audio signal input for testing, can be recorded and saved
Optical Power Meter: Test optical fiber parameters
DC12V Power Output: DC 12V power output, max current 3A, provide temporary power for cameras
DC24V Power Output: DC12V power output, max current 1A, provide temporary power for cameras
PoE Power Output: 48V standard PoE output, provide PoE power for camera
DC5V Power Output: Provide temporary power for USB-powered cameras or emergency power for mobile phones, max current 2A
PSE Voltage Test: Display PoE power supply device voltage and circuit condition
HDMI Video Input Test: Input HD video image into instrument to test video recorder
RS485 Serial Port tool : Can send or receive any data or hex data
Power Charger : DC 12V/2A
Battery: Built-in 7.4V polymer lithium battery, capacity 7000mAh, can work continually for 8-10 hours
Language : Chinese Simplified, Chinese Traditional, English, Germany, Spanish, Portuguese, Russian, French, Polish, Korean, Japanese, Turkish and Italian 13 languages
Internal SD Storage: 8G
Working Temperrature: -10°C--+50°C
Working Humidity: 30%--90%
External Size: 23cm x 14cm x 4.5 cm
Weight : 0.9 kg
•RJ45 cable TDR test,test cable pair status, length, attenuation, reflectivity, impedance, skew etc
•Support PoE 48V output, DC5V ZA O output, DC24 1A output.
•Support Onvif standard pro cameras in the market.
•Screen resolution: HD IPS 1920 x 1200, instant image transmission.
IP discovery tool, it is used to scan the whole network segment IP, and auto-modify tester's IP address. Make your job much more efficient.
Open source, can install Android software. 4K H265, H264, MPEG4 network camera main stream test.
HDMI input and output, 1080P. With Built-in manual book and Browser. Support wireless WIFI(10M/100M/1000M) and hotpots, easily connect and test wireless WIFI camera. RS485 Port: Receive, send and analyze data, used for PTZ protocol analysis, etc. Network tools: to scan all the IP address in the network, and test current network condition and PING value.
It can update software on line on App store. support to take snapshot at any time and the image can by modify 8 times. Rechargeable 7000mA / 7.4V polymer lithium battery. Working hour:6-10 hours.
